Records video/audio in broadcast formats from up to 8 HD-SDI inputs

The standard license includes operation for 2 Channels. Additional channels are optional

Facilitates the ingest (manually and automatically) in iStore PRO database

iStore PRO and iStore INGEST are integrated and share the same database and settings pool

i-Store Ingest™ is able to directly record media from SDI in most popular broadcast formats, or to use broadcast media files already in the local network as its source content, annotate this content according to the Dublin Core standard set of metadata topics, and can ingest the annotated media in the i-Store Pro database, as soon as the recording is complete, or based on a time schedule.

Can ingest the same video simultaneously in two folders (option).

Key capabilities:

• Up to 8 HD‑SDI inputs with embedded timecode and multi-channel audio
• Simultaneous real-time recording of all sources in broadcast formats
• Scheduled multi-channel sync recording for multi-camera workflows
• Direct export-to-database from any channel, even during recording
• Individual transfer speed control for each export job
• Job scheduling and automatic deferral to avoid congestion
• Reliable operation in high-pressure live environments

• Records HD SDI video signals and encodes them in real time in broadcast formats, such as:
• Apple ProRes (LT, normal, HQ)
• Avid DNxHD 145 amd 220
• XDCAM HD 420/422
• DVCPRO HD 100Mb/s
• MJPEG
• IMX
• Massive computing power is required if complex formats are selected for multichannel ingest. Complex server operation can be done using server computers and multi-input Decklink boards.
• Ex: 2 x Xeon 2690 V4, 32GB RAM, Decklink Quad 2 can ingest 8 channels in ProRes or DNxHD. 1 x Xeon 2660 V4, 16GB RAM, Decklink Quad 2 can ingest 4 channels ProRes plus 2 channels playout (32bpp)


• Captures are time scheduled, remote triggered, or manually started (crash record), via per-channel events or as events for multicam recordings
• Each channel has a default video standard (standard list is like in IStore PRO), and a default encoding format settings
• A channel can Schedule an Event to start recording in (the default or) a particular format, in a particular file name (w/o path and extension), at a given precise time (local computer time), and have a determined (maximum) duration
• A channel can schedule an event to start recording in (the default or) a particular format, in a particular file name, when receiving a particular trigger command
• A scheduled recording event can be instructed to stop upon receiving a particular per-event STOP command and to cancel/drop the result upon receiving another particular per-event ABORT command
• A channel can be instructed to stop ANY recording event upon receiving a particular STOP command
• A channel can be instructed to cancel/drop ANY recording event upon receiving a particular ABORT command
• Split While Ingest: Broadcast recording systems often operate continuously, generating large recording files over extended periods. Managing these enormous single files can be challenging and inefficient for users. With iStore Ingest, ingest operators can manually split recordings or configure the system to automatically split files once they reach a specified duration. iStore Ingest ensures that each segment is frame-accurate, maintaining precise alignment even if recording is stopped and restarted. This feature greatly simplifies file management and improves workflow efficiency
• Edit While Ingest: iStore Ingest supports growing files, allowing editors to start working on the recording immediately after the ingest process begins. Whether using Adobe Premiere, DaVinci Resolve, GV Edius, or any compatible editing software, users can access and edit the file while it is still being recorded

Our software products are fully compatible with Blackmagic Design's capture and playback cards, including the DeckLink series. This ensures seamless integration in professional video environments and access to high-quality standards in broadcast and post-production workflows
Supported Blackmagic Design Cards

• DeckLink Series (PCIe)
• DeckLink Quad 2
• Decklink Duo 2
• DeckLink 8K Pro G2
• DeckLink Mini Recorder 4K
• Older Decklink boards with drivers starting from 10.xx

All DeckLink PCI Express (PCIe) cards work in Windows-based workstations and servers, offering excellent flexibility for deployment.

Compatible Operating Systems
Windows: Windows 7, Windows 8, Windows 10, Windows 11

Compatible Video and Audio Standards

• SD, HD, Ultra HD, 4K video formats
• SDI, HDMI, Analog Component, S-Video, Composite connections
• 16 channels of audio input/output
• Blackburst sync input, tri-sync HD input

Connectivity Highlights

• SDI and HDMI outputs for monitors, broadcast decks, projectors, and video equipment.
• Support for older video devices via component analog, S-Video, and composite connections (various DeckLink models)
• Versatile PCIe slot compatibility: Compatible with both 8- and 16-lane PCIe slots, ensuring installation in most modern workstations

In summary:
Using Blackmagic Design DeckLink cards, our software will work on Windows systems and integrate smoothly with leading video, audio, visual effects, and streaming workflows. Both professional and consumer-grade equipment connections are supported, and developer resources are available for custom solutions.
